1

Drying kiln smoke slurry pump

PM0101YZ01

Medium: drying kiln dust slurry

Containing 2% acid (sulfuric acid), containing fluorine ions 100-200mg/L, chloride ions 300-400mg/L,

Pulp temperature ~65℃

Solid content: about 30%

Specific gravity of pulp 1.5t/m3

DYP80-50-400

Q:60m³ /h
H: 50m

2507+ coating

2

Lead silver slurry pump

PM0101YZ02

medium lead silver slag slurry;
Pulp acidity 50 ~ 70g/L (sulfuric acid), fluorine ions 30-40mg/L, chloride ions 500-600mg/L,

Pulp temperature ~ 70℃,

Solid content: about 30%;

Specific gravity of pulp 1.7t/m3

DYP80-50-450

Q:100m³ /h
H: 50m

CD4MCu

3

Iron slurry pump

PM0101YZ03

Medium: iron slag slurry;

Pulp acidity 5 ~ 10g/L (sulfuric acid), fluorine ions 20-30mg/L, chloride ions 500-600mg/L,

Pulp temperature ~ 80℃,

Solid content: about 30%;

Specific gravity of pulp 1.7t/m3

DYP125-100-400

Q:150m³ /h
H: 50m

CD4MCu

4

Sewage slurry pump

PM0101YZ04

Medium: sewage sludge slurry;

Alkaline PH=8.5,

Pulp temperature ~35℃,

Solid content: about 30%;

Pulp specific gravity 1.4t/m3;

DYP80-50-400

Q:60m³ /h
H: 50m

Cr26

5

Washing pump

PM0101YZ15

Medium: washing liquid; Neutral, temperature: room temperature;

DYP80-50-400

Q:60m³ /h
H: 50m

Cr26

6

Zinc oxide iron removal slurry pump

PM0101YZ16

Medium: zinc oxide iron removal slurry;

High fluorine, chlorine (containing fluorine 200-300mg/L,   Chlorine 800-2000 mg/L),

Solid content: about 30%;

Specific gravity of pulp 1.4t/m3,

Temperature 65℃

DYP80-50-450

Q:100m³ /h
H: 50m

2507+ coating

7

Acid pump

PM0107YG04

93-98% concentrated sulfuric acid, specific gravity 1.84t/m3, 40℃

Q:150m³ /h
H: 15m

HT250

8

Slag-slurry pump

PM0204YZ01

Conveying medium: slightly acid corrosion slag slurry, considering corrosion and wear resistance;

Q:20m³ /h
H: 25m

Cr30A

9

Anode slime pump

PM0301YZ01

Transport medium: lead anode mud;
Liquid-solid ratio: 4:1;

Specific gravity: 1.35 ~ 1.4t/m3;

Temperature: ~ 60℃;
Mud acid content: Pb in the form of PbSiF6 is 60 ~ 120g/L, free silicofluoric acid is 60 ~ 120g/L, SiF6-2 total amount is 100 ~ 180g/L; F-4 ~ 8g/L, Cl -0.01 ~ 0.03%;

DYPB65-40-450

Q=25m³ /h     H=66m

Tin bronze

10

First stage filter pump

PM0301YZ11

Transport medium: lead anode mud;
Liquid-solid ratio: 4:1;

Specific gravity: 1.35 ~ 1.4t/m3;

Temperature: ~ 60℃;
Mud acid content: Pb in the form of PbSiF6 is 60 ~ 120g/L, free silicofluoric acid is 60 ~ 120g/L, SiF6-2 total amount is 100 ~ 180g/L, F-4 ~ 8g/L, Cl-0.01 ~ 0.03%;

DYPB80-50-450

Q=50m³ /h     H=70m

Tin bronze

11

First stage slurry pump

PM0301YZ12

Transport medium: lead anode mud;
Liquid-solid ratio: 4:1;

Specific gravity: 1.35 ~ 1.4t/m3;

Temperature: ~ 60℃;
Mud acid content: Pb in the form of PbSiF6 is 60 ~ 120g/L, free silicofluoric acid is 60 ~ 120g/L, SiF6-2 total amount is 100 ~ 180g/L, F-4 ~ 8g/L, Cl-0.01 ~ 0.03%;

DYPB65-40-450A

Q=30m³ /h     H=26m

Tin bronze

12

Two-stage filter pump

PM0301YZ11

Transport medium: lead anode mud;
Liquid-solid ratio: 4:1;

Specific gravity: 1.35 ~ 1.4t/m3;

Temperature: ~ 60℃;
Mud acid content: Pb in the form of PbSiF6 is 60 ~ 120g/L, free silicofluoric acid is 60 ~ 120g/L, SiF6-2 total amount is 100 ~ 180g/L, F-4 ~ 8g/L, Cl-0.01 ~ 0.03%;

DYPB80-50-450

Q=50m³ /h     H=70m

Tin bronze

13

Second stage slurry pump (anode mud slurry pump)

PM0301YZ14

Transport medium: lead anode mud;
Liquid-solid ratio: 4:1;

Specific gravity: 1.35 ~ 1.4t/m3;

Temperature: ~ 60℃;
Mud acid content: Pb in the form of PbSiF6 is 60 ~ 120g/L, free silicofluoric acid is 60 ~ 120g/L, SiF6-2 total amount is 100 ~ 180g/L; F-4 ~ 8g/L, Cl -0.01 ~ 0.03%;

DYPB65-40-450

Q=30m³ /h     H=66m

Tin bronze

14

Condensate transfer pump

PM0301YZ17

Conveying medium: condensate;

Solution specific gravity: 1.0t/m3;

Solution temperature: 40 ~ 80℃;

DYIH50-32-160

Q=5m³ /h     H=25m

304 Stainless steel

15

Pneumatic diaphragm pump

PM0301YZ18

Transport medium: anode mud;
Liquid-solid ratio: 4:1;

Specific gravity: 1.35 ~ 1.4t/m3;

Temperature: ~ 60℃;
Solution composition: The mud contains acid, lead in the form of PbSiF6 is 60 ~ 120g/L, free silicofluoric acid is 60 ~ 120g/L, SiF6-2 total is 100 ~ 180g/L, F-4 ~ 8g/L, Cl-0.01 ~ 0.03%;
Other: The solution may contain very small amounts of floaters and anode slime

QBK-100

Q=30m³ /h     H=31m

Cast steel lining F46
