China Color International Trading Co., Ltd. Congo (Gold) Dizwa copper and cobalt mine project slurry pump
Project name: Dizwa Copper and Cobalt Mine Project
Production time: 2019
Usage of overflow parts: impeller, pump cover 1 year, pump body 8 months
|
Serial number |
Device name |
Medium conditions |
Equipment model |
Equipment parameters |
Material of overcurrent component |
|
1 |
First stage cobalt desanding pump |
True mineral density (t/m3) : 2.5 Feed pulp concentration (w) % : 20 Pulp density (t/m3):1.15 Ore size :≥ 70% -200 mesh Pulp PH value :7-8.5 |
DYP65-A |
Q:50m³ /h |
Cr26 |
|
2 |
First stage cobalt thickener underflow pump |
True mineral density (t/m3) : 2.5 Feed pulp concentration (w) % : 8-20 Pulp density (t/m3):1.15 Ore size: ≥ 70% -200 mesh Pulp PH value :7-8.5 |
DYP65-A |
Q:52m³ /h |
Cr26 |
|
3 |
Second stage cobalt removal pump |
True mineral density (t/m3) : 2.5 Feed pulp concentration (w) % : 20 Pulp density (t/m3):1.15 Ore size: ≥ 70% -200 mesh Pulp PH value :7-8.5 |
DYP65-A |
Q:50m³ /h |
Cr26 |
|
4 |
Second stage cobalt thickener underflow pump |
True mineral density (t/m3) : 2.5 Feed pulp concentration (w) % : 8-20 Pulp density (t/m3):1.15 Ore size: ≥ 70% -200 mesh Pulp PH value: 7-8.5 |
2DYZJ-6 |
Q:21m³ /h |
Cr26 |
|
5 |
Iron slurry pump |
Medium: acid containing wastewater small amount of solid True mineral density (t/m3) : 1.1 Feed pulp concentration (w) % : 30 Pulp density (t/m3):1.25 Pulp PH value :3-5 |
DYP125× 100-LA |
Q:230m³ /h |
A49 |
|
6 |
First stage cobalt filter press feed pump |
Medium: Cobalt hydroxide slurry Feed pulp concentration (w) % : Solid content 8-20 Ore size: 1.15~1.23 Pulp PH value :7.5~9.5 |
DYZA150-315C |
Q:280m³ /h |
Cr26 |
|
7 |
Removal of magnesium sand pump |
Medium: slurry True mineral density (t/m3) : 2.5 Feed pulp concentration (w) % : 20 Pulp density (t/m3):1.15 Ore size: ≥ 70% -200 mesh Pulp PH value :9.5~12 |
DYP65-A |
Q:50m³ /h |
Cr26 |
|
8 |
Magnesium thickener underflow pump |
Medium: Alkaline solution Feed pulp concentration (w) % : 25~35 Pulp density (t/m3):1.2 Ore size: ≥ 70% -200 mesh Pulp PH value :9.5~12 |
DYZA80-450 |
Q:124m³ /h |
Cr26 |
|
9 |
Calcium oxide slurry transfer pump |
Medium: Alkaline solution True mineral density (t/m3) : 2.5 Feed pulp concentration (w) % : 20-30 Pulp density (t/m3):1.2 Ore size: ≥ 70%-200 mesh Pulp PH value :12~14 |
DYP125-J |
Q:170m³ /h |
Cr26 |
|
10 |
Calcium oxide slurry pump |
Medium: Alkaline solution True mineral density (t/m3) : 2.5 Feed pulp concentration (w) % : 20-30 Pulp density (t/m3):1.33 Ore size: ≥ 70% -200 mesh Pulp PH value :12-14 |
DYP80× 50 |
Q:75m³ /h |
Cr26 |
|
11 |
Magnesium oxide slurry pump |
Medium: Alkaline solution True mineral density (t/m3) : 2.5 Feed pulp concentration (w) % : 10-20 Pulp density (t/m3):1.33 Ore size: ≥ 70% -200 mesh Pulp PH value :12-14 |
2DYZJ-4 |
Q:15m³ /h |
Cr26 |
